Adding and Managing printers in Linux using lpadmin command
CUPS: Common UNIX Printing System. In this article we are going to see Adding and Managing Printers in Linux Using lpadmin Command.
lpadmin is a command line tool used to configure printer and managing printing queues provided by CUPS. A system running CUPS is a host that can accept print jobs from client computers, process them, and send them to the appropriate printer. It can also be used to set the server default printer or class.
This article will explain how to add a new printer, setup printer options and manage printers on linux environment using lpadmin command. Verifying and cancelling printing jobs.
Adding and Managing printers in Linux using lpadmin command
1.Installation a NEW printer
To add new printer with the name “HYD_SHIPPING3025” use the lpadmin command with -p option as shown below
Specifies a PostScript Printer Description file to use with the printer. If specified, this option overrides the -i option (interface script).
# lpadmin -p HYD_SHIPPING3025 -v socket://192.168.2.100 -P /usr/share/cups/model/HP/LaserJet-postscript.ppd # lpstat -v device for HYD_SHIPPING3025: socket://192.168.2.100:9100
To verify the if the printer is configured correctly, you can use the command lpstat
# lpstat -p HYD_SHIPPING3025 -l printer HYD_SHIPPING3025 is idle. enabled since Thu 19 Nov 2015 10:46:35 PM PST
2. PPD and log files
PPD: Postscript Printer Description
PPD files are created by vendors describe the entire set of features and capabilities available for their postscript printers and they are usually located under /usr/share/cups/model/ directory.
you have to verify the logs to identify if any printer issues and errors. Log path is below mentioned
# ls -l /var/log/cups/* -rw------- 1 root lp 1455179 Nov 20 00:55 page_log -rw------- 1 root lp 12305457 Nov 20 00:56 error_log -rw------- 1 root lp 11746265 Nov 20 00:56 access_log
3. Configuring printer using parallel port
To configure the printer using parallel port, use the below lpadmin command
# lpadmin -p HYD_SHHIPPING3025 -v parallel://dev/lp0 -m /usr/share/cups/model/DeskJet-cdj880.ppd
4. Multiple printer classes
CUPS always checks for an available printer in the order in which printers were added to a class. You can add 1 or more printers to a class and when on of the printers becomes unavailable, the other printer defined in the class handle the printer job requests.
It is not mandatory to add printers in classes. One printer class can themselves be members of other classes so it is possible for you to define printer classes for high availability for printing. Once you configure the printer class, you can print to the printer class in the same way that you point to a single printer.
5. Add printer to class
To add a printer to the class, use the below command
# lpadmin -h localhost -p HYD_SHIPPING3025 -c yourclass
Verify the printer class
# lpstat -c yourclass
List all the printer classes use below command
# lpstat -c
6. Removing printers from a Class
To remove a printer from the class you can use the lpadmin command as shown below adding and managing printers in linux
# lpstat -x yourclass members of class yourclass: HYD_SHIPPING3025 HPJET1210
Remove HYD_SHIPPPING3205 printer from yourclass as shown below
# lpadmin -p HYD_SHIPPING3025 -r yourclass
Once you remove it, again verify using below command whether it is removed or not
# lpadmin -c yourclass members of class yourclass: HPJET1210
7. Delete a whole Printer Class
Using -x option, we can remove the class.
# lpadmin -c yourclass mebers of class yourclass: HPJET1210 # lpadmin -x yourclass # lpstat -c yourclass lpstat: Unknown destionation "yourclas"!
Please note that the printer configuration still exists even if you removed the class
8. Change Printer Options
To change the printing options for the printer, you can execute the below commands.
List all available options for the printer using lpoptions command as shown below.
# lpoptions -p HYD_SHIPPING3025 -l PageSize/Page Size: *Letter A4 11x17 A3 A5 B5 Env10 EnvC5 EnvDL EnvISOB5 EnvMonarch Executive Legal PageRegion/PageRegion: Letter A4 11x17 A3 A5 B5 Env10 EnvC5 EnvDL EnvISOB5 EnvMonarch Executive Legal InputSlot/Media Source: *Default Tray1 Tray2 Tray3 Tray4 Envelope Manual Resolution/Resolution: 75x75dpi 150x150dpi *300x300dpi
9. Change Printer Resolution
To Change the resolution of the printer to 400x400dpi, you can use the lpadmin command as shown below
# lpadmin -p HYD_SHIPPING3025 -o Resolution=400x400dpi
Verify the options has been changed using below command
# lpadmin -p HYD_SHIPPING3025 -l
Here are the other options you can set for any printer using lpadmin with –o option as described in above example,
- job-k-limit=value – Sets the kilobyte limit for per-user quotas. The value is an integer number of kilobytes.
- job-page-limit=value – Sets the page limit for per-user quotas. The value is the integer number of pages that can be printed; double-sided pages are counted as two pages.
- job-quota-period=value – Sets the accounting period for per-user quotas. The value is an integer number of seconds.
- job-sheets-default=banner – Sets the default banner pages to use for print jobs.
- name=value – Sets a PPD option for the printer. PPD options can be listed using the -l option with the lpoptions(1) command.
- name-default=value – Sets a default server-side option for the printer.
- port-monitor=name – The specified port monitor must be listed in the printer’s PPD file.
- printer-error-policy=name – Sets the error policy to be used when the printer backend is unable to send the job to the printer.
- printer-is-shared=true/false – Sets the printer to shared/published or unshared/unpublished.
- printer-op-policy=name – Sets the IPP operation policy associated with the printer. The name must be defined in the cupsd.conf in a Policy section. The default operation policy is “default”.
10. Remove Printer
To remove the printer from the printer configuration file, you can use the -x option as shown below:
# lpstat -v devide for HYD_SHIPPING3025: socket://192.168.2.100:9100 # lpadmin -x HYD_SHIPPING3025 #lpstat -v lpstat: No destination added.
12. Allow/Deny User or Groups to Configure Printer Options
You can allow the individual users or group to configure the printer options using lpadmin commands.
The following command will allow the user ark to configure the printer option on HPLaserJetP3015 printer:
# lpadmin -p HPLaserJetP3015 -u allow:ark
You can also block the user from changing the settings/options or configure printer using the below command.
The following command will deny the user ark to configure the printer option on HPLaserJetP3015 printer:
# lpadmin -p HPLaserJetP3015 -u deny:ark
If there is a group that needs to be allowed access, you can use the group name preceding with @ symbol. Multiple user names or groups can be given separated by commas.
For example, the following will allow users from sysadmin group to configure printer options.
# lpadmin -p HPLaserJetP3015 -u allow:@sysadmin
The following will deny users from developer group to configure printer options.
# lpadmin -p HPLaserJetP3015 -u deny:@developer
Stay tune for the Next article print queue management
